CBRS (3 GHz) or unlicensed (5 GHz, 6 GHz)
Up to 1.6 Gbps aggregate capacity per link*
Up to 3.2 Gbps capacity per sector
Up to 12.8 Gbps capacity per cell (4 BNs)*
Up to 250 clients per sector
Fiber-class speeds and reliability at a fraction of the time and cost to deploy
Up to 1000 clients per cell (4 BNs, 250 RNs per BN)
Works in NLoS and nLoS conditions
Cancels interference
Large numbers of radios on both the BN and RN increase precision of all algorithms and enable more complex & accurate techniques (O(n3) rather than just O(n)).
Applying signal processing across time, frequency, and spatial domains yields a perfect channel even with the most complex diffraction, reflection, and motion effects; this enables the G1 platform to deliver excellent performance despite nLoS and NLoS conditions (buildings, foliage).
Cancels up to 40 dB of asynchronous interference from any source outside the network. The before & after graphic shows how the ABIC innovation extracts the 256-QAM constellation from the noise, with each bit of the signal (represented by dots) is crisp and cleanly transmitted.
